Radial Grinding

Your One-Stop Shop

Radial Grinding has over 41 years of experience, providing ID, OD, surface grinding, honing, vertical, centerless and Blanchard grinding. We provide all projects with an inspection report and documentation package. Our core values are customer service and quality.

Contact us today. We look forward to working with you on all of your grinding needs.

What Sets Radial Grinding Apart

  • Quality control room, temperature and humidity regulated
  • CMM (Mitutoyo) inspection capabilities
  • Records – electronic and hard copy – retained for 10 years
  • Environmentally conscious operations
  • One stop
    • Grind, chrome, final grind
    • Grind, ceramic spray, final grind
    • Grind, weld repair, final grind
    • Grind, metalizing, final grind
  • Local pick up and delivery at no charge

Capabilities

Download a PDF file of our capabilities.

The Industries We Serve

Your Innovation – Our Expertise

No job too big or too small – we serve customers with one machine in their basement to Fortune 500 companies!

Capabilities

I.D. GRINDING: 42″ O.D. x 30″ DEEP
SPRINGFIELD VERTICAL, HEALD, CINCINNATI & KELLENBERGERS
O.D. GRINDING: 20″ O.D. x 134″ LONG BETWEEN CENTERS
36″ O.D. x 30″ DEEP
JIG GRINDING: #3 MOORE JIG GRINDERS (2 each)

  • WORK ENVELOPE – 24″ x 28″ x 12″ TALL
  • HOLE SIZE – .050″ – 6.00” x 2″ – 3″ DEEP (DEPENDS ON SIZE)
  • ONE DAY TURNAROUND AVAILABLE
CENTERLESS GRINDING: THRU FEED – .080″ O.D. TO 3″ O.D. X 7′ LONG
INFEED – .125″ O.D. TO 3″ O.D. X 8″ LONG
WEIGHT LIMIT – 120 LBS



STRAIGHTENING: EITEL 44 TON PRESS
BETWEEN CENTERS OR ON DIAMETERS
BAR STOCK, LEAD SCREWS & MULTIPLE DIAMETER
HEAT STRAIGHTENING
HONING: I.D. SIZE RANGE – .070″ TO 8″
LENGTH RANGE –  UP TO 18″
BLANCHARD GRINDING: 42″ TABLE – MARPOSS SIZE GAUGING
HEIGHT OF PART – 22″
ONE MACHINE NEW FROM BLANCHARD – 1999
ONE MACHINE NEW – 2008
SURFACE GRINDING: TABLE SIZE – 16″ x 32″ – OKAMOTO
TABLE SIZE – 24″ x 60″ – OKAMOTO

WELDING REPAIR: WELD – GRIND REPAIR
CHROME REPAIR: GRIND – CHROME – GRIND REPAIR
CYLINDRICAL POLISHING: 1″ O.D. TO 6″ O.D.
BROKEN BOLTS OR TAPS: EDM REMOVAL
OTHER SERVICES:
  • REGRINDING DEAD & LIVE CENTERS
  • TEMPERATURE CONTROLLED Q.C. ROOM
  • PICK UP & DELIVERY AVAILABLE
  • SANDBLAST TO REMOVE HEAT TREAT SCALE BEFORE GRINDING

Find out what we can do for you

Akron Gear Shaft

RE-CENTERING CUSTOMERS SHAFT

Contact Us

Radial Grinding now offering

TRUMPF laser marking: TruMark Station 3000

Laser marking is a catch-all term for several processes:

  • Engraving
  • Ablation
  • Tempering
  • Coloring
  • Foaming

Whatever method is the right one depends on the material and the quality requirements.

Watch the TruMark Station 3000 in action



Read More

Springfield Vertical Grinding

Watch Now

ID Grinding Off Magnetic Chuck

Watch Now

Indicating Part in on Grinding Machine

Watch Now

O.D. Grinding Between Centers

Watch Now

O.D. Grinding Between Centers #2

Watch Now

Honing & Power Stroking Machine

Watch Now

O.D. Grinding & Measuring

Watch Now

Centerless Grinding Setup

Watch Now

Surface Grinding

Watch Now
